Pomace Dryer
Pomace Dryer Introduction
Fruit pomace is the residue left after fruit processing factories produce fruit-based products. Pomace has a high moisture content and is rich in crude protein, vitamins, and trace elements. However, due to its high moisture content, fruit pomace is challenging to store. After drying, fruit pomace can be used not only as feed for livestock farming but also as fertilizer for mushroom cultivation. Henan Ruiao has developed dedicated drying equipment based on the characteristics of fruit pomace.
Pomace Dryer System
The Henan Ruiao fruit pomace drying system consists of a heat source, a belt conveyor, a drum device, a discharger, a dust removal device, a belt discharger, an induced draft fan, and electrical controls.
Pomace Dryer Advantages
1. High Thermal efficiency
The three-channel cylinder of the pomace dryer has a good self-heating effect, which greatly reduces heat loss; the thermal efficiency can reach 80%.
2. Space and Cost Saving
It’s floor space is smaller than the traditional dryer, reduces the plant area and saves about 40% of the project investment. 50% saving in power consumption;
3. Easy Operation
The pomace drying system adopts fully automatic control, which is simple and convenient to operate, it can run continuously for 24 hours, and has a long service life;
4. Various Heating Source Available
Pomace dryer can use various heat sources, such as hand-fired hot air stove, oil-fired boiler in large power plant, direct or indirect hot air stove, gas, fuel oil, coal-fired stove, etc. It is convenient for users to choose according to their actual situation.
Technical Parameters
Model | RASG2010-3 | RASG2209-3 | RASG2609-3 | RASG3009-3 |
Capacity | 1-2t/h | 1-2t/h | 2-3t/h | 4-6t/h |
Input moisture | 35-60% | |||
Output moisture | 12-15% | |||
Drying temperature | 450℃ | |||
Floor space | 10m×20m | 10m×20m | 15m×30m | 15m×40m |
