Beer Yeast Dryer
Beer Yeast Dryer Introduction
The yeast dryer uses steam heating to indirectly conduct heating to heat the yeast and evaporate water; In view of the heat sensitivity of beer yeast, low temperature drying is adopted to maintain the yeast characteristics. This equipment is suitable for drying sticky and paste yeast.
Beer Yeast Dryer System
The yeast dryer consists of a drying cylinder, frame, transmission system, scraper device, material limiting and scraping device, exhaust hood, soaking device, and steam path system. It is equipped with an electrical control cabinet and exhaust hood, and can be used for drying various slurry.
Beer Yeast Drye Features
1. The drying cylinder in contact with yeast is made of high-grade ground cast iron, which is corrosion-resistant and non polluting.
2. High thermal efficiency, generally ranging from 80% to 90%.
3. Adjustable equipment parameters, such as feed concentration, coating film thickness, heating medium temperature, drum rotation speed, etc., It can meets different drying requirements.
Beer Yeast Drye Technical Parameters
Model | RAD2000×2000 | RAD2000×2500 | RAD2000×3000 | JHD2500×4000 | JHD3000×4000 |
Capacity（kg/h) | 50-65 | 60-80 | 70-100 | 120-180 | 150-250 |
Drum size （mm） | Φ 2000×2000 | Φ 2000×2500 | Φ 2000×3000 | Φ 2500×4000 | Φ 3000×2500 |
Rotation speed （r/min） | 4-8 | 4-8 | 4-8 | 4-8 | 4-8 |
Steam working pressure （Mpa） | 0.15-0.3 | 0.15-0.3 | 0.3-0.5 | 0.3-0.8 | 0.3-0.8 |
Steam consumption （kg/h） | 320-390 | 360-480 | 370-500 | 400-600 | 450-800 |
Main motor power （kw） | 11 | 15 | 18.5 | 37 | 45 |
Total weight （T) | 10.7 | 12.2 | 13.5 | 21.0 | 25.0 |
